This
module receives counting signal from a single or paired loop detectors
and perform vehicle counting. Each loop signal incorporates noise and
debounce rejection filter which can be freely programmable.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Technical
Data
|
SS-800-VMC4408N
|
| Number
of inputs |
14
|
| Number
of outputs |
6
|
| Input
type |
NPN
|
| Input
status indication |
Green LED
|
| Output
status indication |
Red LED
|
| Bus
protocol |
eCAN, CANOpen*,
DeviceNet*
|
| Degree
of protection |
IP20
|
| Current
consumption |
120mA
|
| Supply
voltage |
DC24V (+/- 20%)
|
| Weight |
200gm
|
| Dimension
(L x W x H) |
72mm x 64mm x 30mm
(exclude bus connector)
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*
Contact Scientec for availability |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
