This module is an intelligent closed loop precision servo motion controller for standard industrial current or speed motor drives.

Input and output signal status are indicated by LEDs.
Technical Data
SS-800-SRV0218N
Number of axis
2
Number of dedicated inputs
8
Number of dedicated outputs 2
Number of general I/O 4
Input type
NPN
Input status indication
Green LED
Output status indication
Red LED
Encoder supported Quadrature incremental encoder with index pulse input
Control algorithm (PID digital filter) with 16-bit coefficients
Bus protocol
eCAN, CANOpen*, DeviceNet*
Degree of protection
IP20
Current consumption
230mA
Supply voltage
DC24V (+/- 20%)
Weight
200gm
Dimension (L x W x H)
72mm x 64mm x 30mm (exclude bus connector)

* Contact Scientec for availability
