This module receives control signals from digital field devices (sensors, switches, etc.).

Each input points incorporates a noise or debounce rejection filter. The filter time constant can be freely programmable. All input points contains an optocoupler which provides electrical isolation between the module and the field devices. Different modes can be selected to perform special functions like fast-counting. All input points status are indicated by LEDs.

Technical Data
SS-800-DI32P *
Number of inputs
32
Input type
PNP
Input status indication
Green LED
Bus protocol
eCAN, CANOpen*, DeviceNet*
Degree of protection
IP20
Current consumption
120mA
Supply voltage
DC24V (+/- 20%)
Weight
200gm
Dimension (L x W x H)
72mm x 64mm x 30mm (exclude bus connector)

* Contact Scientec for availability
